Request Datasheet
Linear Actuator
SLA05 1,500 N linear actuator
SLA05 1500N linear actuator from Elerover.
Key specifications
- Maximum load
- 1500 N Operating Frequency : 20% Maximum Self-locking Power : 2000 N Maximum Load
- Duty cycle
- 25% at high speed, 10% Construction : In
Product overview
SLA05 1500N linear actuator from Elerover. This DC linear actuator is built for OEM equipment that needs repeatable push/pull motion under industrial duty.
- Maximum load
- 1500 N Operating Frequency : 20% Maximum Self-locking Power : 2000 N Maximum Load
- Duty cycle
- 25% at high speed, 10% Construction : In
Applications
- fitness equipment : electric foot sofas
Benefits
- Voltage : DC 12V/24V
- Rated Load Coefficient : 0.2 inches (5 mm) / s (1500N)
- Mechanical Properties : Operating Temperature : -4°F to 145°F (-26°C to 65°C)
- Material : Aluminum alloy shell and aluminum alloy extension rod
- Available Voltages : 12 or 24 VDC
- Motor : High Speed Motor
- Built-in Limit Switch : Ensures precise control
- No-load Rate : High efficiency at various loads
Technical specifications
| Maximum load | 1500 N Operating Frequency : 20% Maximum Self-locking Power : 2000 N Maximum Load |
|---|---|
| Duty cycle | 25% at high speed, 10% Construction : In |
| Operating temperature | -4°F to 145°F (-26°C to 65°C) Material |
Request technical documents
FAQ
What is the SLA05?
The SLA05 is an Elerover linear actuator for industrial and OEM motion projects.
Does Elerover manufacture the SLA05?
Yes. Elerover is a linear actuator manufacturer and supplier. This model supports OEM configuration options listed in the product data—share your duty cycle and quantity for a factory quote.
What are the key specifications of the SLA05?
Key ratings from the product specifications include load 1500 N. See the Technical Specifications section on this page for the full table.
How do I request a quote for the SLA05?
Send load, stroke, voltage, IP rating, duty cycle, quantity and any OEM options you need via the contact form or WhatsApp.
Request an OEM quote
Share force, stroke, voltage and quantity. Elerover will map your RFQ to a published series or OEM configuration.
Quote context
