SLA-15K 15,000 N linear actuator for solar tracker

Benefits

• Flexible Input Voltage : The SLA-15K offers multiple input voltage options, including 12V DC, 24V DC, 36V DC , and 48V DC , ensuring seamless integration into different power systems.
• No-Load Speed : Achieves a no-load speed of 6.5mm/s , ensuring efficient and rapid movements.
• Load Speed : Operates at a load speed ranging from 2.5mm/s to 3mm/s , providing controlled motion under heavy loads.
• High Load Capacity : Capable of handling a maximum load of 10000N (approximately 1000kg) or 15000N (approximately 1500kg) , making it suitable for demanding applications.
• Self-Locking Force : Equipped with a self-locking force of 30000N (approximately 3000kg) , the actuator can securely hold its position without power, enhancing safety.
• Usage Frequency : Designed for reliable performance with a usage frequency of 10% and a duty cycle of 2 minutes on and 18 minutes off , allowing prolonged operation without efficiency loss.
• Travel Switch : The built-in inner travel switch enables accurate positioning and control, ensuring precise and repeatable motion.
• Ambient Temperature Range : Operates effectively in temperatures from -20 to 65 degrees Celsius , making it suitable for indoor and outdoor applications.
