Request Datasheet
Electric Hydraulic Actuator
Model LD50-173
Outboard Hydraulic Warper LD50-173
Outboard Hydraulic Warper LD50-173 from Elerover.
Key specifications
- Maximum push force
- 1.8 t
- Stroke
- 173 mm
- Speed
- 10–11 mm/s
- Voltage
- DC 12 V / 24 V / 48 V
Product overview
Outboard Hydraulic Warper LD50-173 from Elerover. This electric-hydraulic actuator combines electric drive with hydraulic force for high-load linear motion.
- Maximum push force
- 1.8 t
- Stroke
- 173 mm
- Voltage
- DC 12 V / 24 V / 48 V
- Speed
- 10–11 mm/s
Applications
- Lifting
Benefits
- Reliable Electric Hydraulic Actuator solution for OEM projects
- Robust mechanical design for continuous duty
- Flexible voltage and mounting options
- Custom configurations available on request
Technical specifications
| Maximum push force | 1.8 t |
|---|---|
| Stroke | 173 mm |
| Voltage | DC 12 V / 24 V / 48 V |
| Speed | 10–11 mm/s |
| Mounting type | Outboard mounting — confirm stroke and lift against application |
Request technical documents
FAQ
What is the Outboard Hydraulic Warper LD50-173?
The Outboard Hydraulic Warper LD50-173 is an Elerover electric hydraulic actuator for industrial and OEM motion projects.
Does Elerover manufacture the Outboard Hydraulic Warper LD50-173?
Yes. Elerover is a electric hydraulic actuator manufacturer and supplier. This model supports OEM configuration options listed in the product data—share your duty cycle and quantity for a factory quote.
What are the key specifications of the Outboard Hydraulic Warper LD50-173?
Key ratings from the product specifications include voltage DC 12 V / 24 V / 48 V, stroke 173 mm. See the Technical Specifications section on this page for the full table.
How do I request a quote for the Outboard Hydraulic Warper LD50-173?
Send load, stroke, voltage, IP rating, duty cycle, quantity and any OEM options you need via the contact form or WhatsApp.
Request an OEM quote
Share force, stroke, voltage and quantity. Elerover will map your RFQ to a published series or OEM configuration.
