Request Datasheet
Linear Actuator
SLA08B 7,000 N linear actuator
SLA08B 7000N linear actuator from Elerover.
Key specifications
- Maximum load
- 7000 N
- Stroke
- 50 / 100 / 150 / 200 / 250 / 300 / 350 / 400 / 450 / 500 / 550 / 600 mm (optional and customizable) Loa
- Speed
- 5.5 mm/s – 35.0 mm/s
- Voltage
- 12 V / 24 V / 36 V / 48 V DC
Product overview
SLA08B 7000N linear actuator from Elerover. This DC linear actuator is built for OEM equipment that needs repeatable push/pull motion under industrial duty.
- Maximum load
- 7000 N
- Stroke
- 50 / 100 / 150 / 200 / 250 / 300 / 350 / 400 / 450 / 500 / 550 / 600 mm (optional and customizable) Loa
- Speed
- 5.5 mm/s – 35.0 mm/s
- Voltage
- 12 V / 24 V / 36 V / 48 V DC
- IP rating
- IP65
- Duty cycle
- 25% (4 min continuous moving) IP Rat
Applications
- Construction
- Wheelchair
Technical specifications
| Maximum load | 7000 N |
|---|---|
| Stroke | 50 / 100 / 150 / 200 / 250 / 300 / 350 / 400 / 450 / 500 / 550 / 600 mm (optional and customizable) Loa |
| Speed | 5.5 mm/s – 35.0 mm/s |
| Voltage | 12 V / 24 V / 36 V / 48 V DC |
| IP rating | IP65 |
| Duty cycle | 25% (4 min continuous moving) IP Rat |
Performance matrix
| No-load speed | Full-load speed | Thrust | Self-locking force |
|---|---|---|---|
| 5.5 mm/s | 4.0 mm/s | 7000 N | 10000 N |
| 8.5 mm/s | 7.0 mm/s | 7000 N | 10000 N |
| 11.0 mm/s | 9.5 mm/s | 5000 N | 8000 N |
| 17.0 mm/s | 14.0 mm/s | 4000 N | 7000 N |
| 22.0 mm/s | 18.0 mm/s | 3000 N | 5000 N |
| 35.0 mm/s | 28.5 mm/s | 2000 N | 4000 N |
Request technical documents
FAQ
What is the SLA08B?
The SLA08B is an Elerover linear actuator rated IP65.
Does Elerover manufacture the SLA08B?
Yes. Elerover is a linear actuator manufacturer and supplier. This model supports OEM configuration options listed in the product data—share your duty cycle and quantity for a factory quote.
What are the key specifications of the SLA08B?
Key ratings from the product specifications include voltage 12 V / 24 V / 36 V / 48 V DC, load 7000 N, stroke 50 / 100 / 150 / 200 / 250 / 300 / 350 / 400 / 450 / 500 / 550 / 600 mm (optional and customizable) Loa, protection IP65. See the Technical Specifications section on this page for the full table.
How do I request a quote for the SLA08B?
Send load, stroke, voltage, IP rating, duty cycle, quantity and any OEM options you need via the contact form or WhatsApp.
Request an OEM quote
Share force, stroke, voltage and quantity. Elerover will map your RFQ to a published series or OEM configuration.
