Linear Actuator
Model SLA08
SLA08 10,000 N linear actuator
SLA08 10000N linear actuator from Elerover.
Key specifications
- Maximum load
- 8000 N / 800 kg
- Stroke
- 50–1000 mm (customizable)
- Speed
- 5 mm/s (800KG) -80 mm/s (50KG)
- Voltage
- 12 V / 24 V / 36 V / 48 V DC
Product overview
SLA08 10000N linear actuator from Elerover. This DC linear actuator is built for OEM equipment that needs repeatable push/pull motion under industrial duty.
- Maximum load
- 8000 N / 800 kg
- Stroke
- 50–1000 mm (customizable)
- Speed
- 5 mm/s (800KG) -80 mm/s (50KG)
- Voltage
- 12 V / 24 V / 36 V / 48 V DC
- IP rating
- IP54 / IP65
Applications
- Lifting platforms
- Construction machinery
- Heavy industry equipment
- Solar tracking
Benefits
- Heavy-duty SLA08 industrial electric linear actuator
- Up to 8000N (800 kg) push/pull force
- 12V / 24V / 36V / 48V DC voltage options
- IP54 / IP65 protection options
- Built-in limit switches; optional Hall feedback
- Retracted install length L = stroke + 250mm
Technical specifications
| Maximum load | 8000 N / 800 kg |
|---|---|
| Stroke | 50–1000 mm (customizable) |
| Speed | 5 mm/s (800KG) -80 mm/s (50KG) |
| Voltage | 12 V / 24 V / 36 V / 48 V DC |
| IP rating | IP54 / IP65 |
| Retracted length | L = S + 250 mm |
| Extended length | 2*S (stroke) + 250 mm |
| Limit switch | Built-in |
| Operating temperature | -26℃~65℃ |
| Certifications | CE |
Request technical documents
FAQ
What is the SLA08?
The SLA08 is an Elerover linear actuator rated IP54.
Does Elerover manufacture the SLA08?
Yes. Elerover is a linear actuator manufacturer and supplier. This model supports OEM configuration options listed in the product data—share your duty cycle and quantity for a factory quote.
What are the key specifications of the SLA08?
Key ratings from the product specifications include voltage 12 V / 24 V / 36 V / 48 V DC, load 10000 N, stroke 50–1000 mm (customizable), protection IP54. See the Technical Specifications section on this page for the full table.
How do I request a quote for the SLA08?
Send load, stroke, voltage, IP rating, duty cycle, quantity and any OEM options you need via the contact form or WhatsApp.
Request an OEM quote
Share force, stroke, voltage and quantity. Elerover will map your RFQ to a published series or OEM configuration.
Quote context
