Linear Actuator
Model SLA-T52
SLA-T52 6,000 N IP68 waterproof linear actuator
SLA-T52 6000N IP68 waterproof linear actuator from Elerover.
Key specifications
- Maximum load
- 6000 N
- Stroke
- 20 – 500 mm
- Voltage
- 12 V / 24 V DC
- IP rating
- IP68
Product overview
SLA-T52 6000N IP68 waterproof linear actuator from Elerover. This DC linear actuator is built for OEM equipment that needs repeatable push/pull motion under industrial duty.
- Maximum load
- 6000 N
- Stroke
- 20 – 500 mm
- Voltage
- 12 V / 24 V DC
- IP rating
- IP68
- Feedback
- Optional
- Duty cycle
- 10%
Applications
- Outdoor automation
- Marine-adjacent equipment
- Industrial wet environments
Benefits
- Inline / tubular Ø52 mm envelope
- Up to 6000 N (5000 N max at 12 V)
- 12 V / 24 V DC with built-in limit switches
- Optional Hall sensor for synchronization
- IP68 sealed construction for wet environments
- OEM stroke, voltage and feedback options
Technical specifications
| Maximum load | 6000 N |
|---|---|
| Stroke | 20 – 500 mm |
| Voltage | 12 V / 24 V DC |
| IP rating | IP68 |
| Duty cycle | 10% |
| Feedback | Optional |
| Limit switch | Built-in, non-adjustable |
| Noise level | < 60 dB |
| Housing material | Aluminum alloy |
| Rod material | Stainless steel |
| Operating temperature | -25°C to +65°C |
Request technical documents
FAQ
What is the SLA-T52?
The SLA-T52 is an Elerover linear actuator rated IP68.
Does Elerover manufacture the SLA-T52?
Yes. Elerover is a linear actuator manufacturer and supplier. This model supports OEM configuration options listed in the product data—share your duty cycle and quantity for a factory quote.
What are the key specifications of the SLA-T52?
Key ratings from the product specifications include voltage 12 V / 24 V DC, load 6000 N, stroke 20 – 500 mm, protection IP68. See the Technical Specifications section on this page for the full table.
How do I request a quote for the SLA-T52?
Send load, stroke, voltage, IP rating, duty cycle, quantity and any OEM options you need via the contact form or WhatsApp.
Request an OEM quote
Share force, stroke, voltage and quantity. Elerover will map your RFQ to a published series or OEM configuration.
